河源市源城区鸿信超声波智能设备有限公司

⦁ 全新设计扫频追频线路，可在0.5秒内扫频并锁定，极大程度降低了换能器与模具在开机扫频时的不必要损伤；
⦁ 系统升级至恒定振幅线路，不受外部电压的变化影响，始终保持工作时的高压、高振幅输出；
⦁ 可实现分段转速，及分段扭力的控制，特别针对PP/PA材质的焊接达到彻底熔胶；
⦁ 原点可随意高度的设置，有效的提升焊接时的工作效率；
⦁ The newly designed frequency scanning and tracking circuit can scan and lock in frequency within 0.5 seconds, greatly reducing unnecessary damage to the transducer and mold during startup frequency scanning;
⦁ The system is upgraded to a constant amplitude circuit, unaffected by external voltage changes, and always maintains high voltage and high amplitude output during operation;
⦁ It can achieve segmented speed control and segmented torque control, especially for the welding of PP/PA materials to achieve complete adhesive melting;
⦁ The origin can be set at any height, effectively improving the work efficiency during welding;

⦁ 高强度钢制机架，高压高速状态下工作坚固无后仰；
⦁ 选用知名品牌伺服电机系统，可有效保障运行时精度可控在0.01mm；
⦁ 电机升降机身，可降低人员操作时的疲劳程度；
⦁ 选用底板水平调整方式，确保使用过程中水平位始终不变；
⦁ 配备多种焊接模式（时间、能量、功率、绝对深度、相对深度）可兼顾多种不同焊接应用；
⦁ 可支持同时开启或单独启用焊接时的品质监控；
⦁ 可接入MES系统实时上传焊接数据，可扩展至上位机功能并支持扫码对应记录数据；
⦁ 实时显示焊接曲线，可直观了解焊接时的动态走向；
⦁ 可存储多组数字或字母结合命名的焊接数据，便于操作人员查找；
⦁ 可存储多条焊接记录，并导出至PC端，便于品质管理的追溯查找；
⦁ 可设置分段的振幅，降低焊接时内部件的损坏、表面的烫伤；
⦁ High strength steel frame, sturdy and without tilting under high-pressure and high-speed conditions;
⦁ Using a well-known brand servo motor system can effectively ensure that the accuracy during operation is controllable within 0.01mm;
⦁ The motor lifts the machine body, which can reduce the fatigue level of personnel during operation;
⦁ Select the bottom plate horizontal adjustment method to ensure that the horizontal position remains unchanged during use;
⦁ Equipped with multiple welding modes (time, energy, power, absolute depth, relative depth), it can accommodate various welding applications;
⦁ Can support quality monitoring when welding is enabled simultaneously or separately;
⦁ It can be connected to the MES system to upload welding data in real time, and can be extended to the upper computer function and support scanning corresponding record data;
⦁ Real time display of welding curves, allowing for intuitive understanding of the dynamic direction during welding;
⦁ It can store welding data named by combining multiple sets of numbers or letters, making it easy for operators to search;
⦁ Can store multiple welding records and export them to the PC for easy traceability and search of quality management;
⦁ Segmented amplitude can be set to reduce damage to internal components and surface burns during welding;
